CENTRIFUGES
Whirlybyrds Inc. has various sizes of centrifuges to satisfy your requirements.
Centrifuge KW7000 (with backdrive)
c/w shale bin/ hydraulic or cable-lift centrifuge stand combination
BOWL SIZE 30 x 70 inch
HYDRAULIC FLOW RATE 2.5 m3/min
VOLTAGE 600 volts
Requires (2) 100 amp / 3w4p outlets
MOTOR Main drive: 200 HP
Backdrive: 60 HP
SOLIDS CAPACITY Up to 28 ton/h
(62,500 lbs/h)
Centrifuge KW5200 (with backdrive)
c/w shale bin/ hydraulic or cable-lift centrifuge stand combination
BOWL SIZE 21 x 52 inch
HYDRAULIC FLOW RATE 1.5 m3/min
VOLTAGE 600 V / 3 Ph / 60Hz
Requires (1) 100 amp / 3w4p outlets
MOTOR Main drive: 100 HP
Backdrive: 25 HP
SOLIDS CAPACITY Up to 18 ton/h
(40,000 lbs/h)
Lynx 40 Alfa Laval (with backdrive)
Available with dual hydraulic centrifuge stand combination.
Specifications below are for each centrifuge:
BOWL SIZE 19 x 80 inches
HYDRAULIC FLOW RATE 1.7 m3/min
VOLTAGE 480V
Requires (2) 100A / 3W 4P plugs
MOTOR Main drive:125 HP
Backdrive: 20 HP
SOLIDS CAPACITY Up to 12 ton/h
(26,000 lbs/h)
Lynx 20 Alfa Laval (with backdrive)
Available with dual hydraulic centrifuge stand combination.
Specifications below are for each centrifuge:
BOWL SIZE 14 x 57.5 inches
HYDRAULIC FLOW RATE .85 m3/min
VOLTAGE 480V
100A / 3W 4P plug
MOTOR Main drive: 50 HP
Backdrive: 30 HP
SOLIDS CAPACITY Up to 5 ton/h
(11,000 lbs/h)
